ASME SA106 API 5L A53 Grade B Carbon Steel Seamless Pipe for Oil and Gas Industry

Brand Name : YUHONG

Model Number : ASME SA106

Certification : ASME , U STAMP , PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS

Place of Origin : CHINA

MOQ : 1PC

Price : 1--10000 USD

Payment Terms : L/C, T/T

Supply Ability : 10000 Tons/Month

Delivery Time : 5---75 Tons

Packaging Details : Ply-wooden Case /Iron Case/ Bundle with plastic Cap etc.

Standard : ASME SA106

Equivalent Grade : ASTM A53

Material : Grade B

Type : Seamless

Non destructive Test : Hydrostatic test, Eddy Current Test, Ultrasonic Test

Contact Now

ASME SA106 API 5L A53 Grade B Carbon Steel Seamless Pipe for Oil and Gas Industry

In the oil and gas industry, where reliability and durability are crucial, ASME SA106 Grade B carbon steel seamless pipes stand out. Engineered to endure high - temperature, high - pressure conditions, they ensure the safe and efficient transport of fluids, making them an essential choice for critical pipeline infrastructure.

ASME SA106 Grade B Carbon Steel Seamless Pipe Chemical Requirements

Composition(%) Carbon(max) Manganese Phosphorus(max) Sulfur(min) Silicon(min) Chromium(max) Copper(max) Molybdenum(max) Nickel(max)
Grade B 0.3 0.29 - 1.06 0.035 0.035 0.1 0.4 0.4 0.15 0.08

ASME SA106 Grade B Carbon Steel Seamless Pipe Tensile Requirements

Property

Tensile strength, min

Yield strength, min

Grade B

60,000 psi (415 MPa)

35,000 psi (240 MPa)

ASME SA106 Grade B Carbon Steel Seamless Pipe Common Size

NPS DN OD 5s 10s 10 20 30 40s STD 40 60 80s XS 80 100 120 140 160 XXS
3/4 20 26.7 1.65 2.11 2.87 2.87 2.87 3.91 3.91 3.91 5.56 7.82
1 25 33.4 1.65 2.77 3.38 3.38 3.38 4.55 4.55 4.55 6.35 9.09
1 1/4 32 42.2 1.65 2.77 3.56 3.56 356 4.85 4.85 4.85 6.35 9.70
1 1/2 40 48.3 1.65 2.77 3.68 3.68 3.68 5.08 5.08 5.08 7.14 10.15
2 50 60.3 1.65 2.77 3.91 3.91 3.91 5.54 5.54 5.54 8.74 11.07
2 1/2 65 73 2.11 3.05 5.16 5.16 5.16 7.01 7.01 7.01 9.53 14.02
3 80 88.9 2.11 3.05 5.49 5.49 5.49 7.62 7.62 7.62 11.13 15.24
3 1/2 90 101.6 2.11 3.05 5.74 5.74 5.74 8.08 8.08 8.08
4 100 114.3 2.11 3.05 6.02 6.02 6.02 8.56 8.56 8.56 11.13 13.49 17.12
5 125 141.3 2.77 3.40 6.55 6.55 6.55 9.53 953 9.53 12.70 15.88 19.05
6 150 168.3 2.77 3.40 7.11 7.11 7.11 10.97 10.97 10.97 14.27 18.26 21.95
8 200 219.1 2.77 3.76 6.35 7.04 8.18 8.18 8.18 10.31 12.70 12.70 12.70 15.09 18.26 20.62 23.01 22.23
10 250 273.1 3.40 4.19 6.35 7.80 9.27 9.27 9.27 12.70 12.70 12.70 15.09 18.26 21.44 25.40 28.58 25.40
12 300 323.9 3.96 4.57 6.35 8.38 9.53 9.53 10.31 14.27 12.70 12.70 17.48 21.44 25.40 28.58 33.32 25.40
14 350 355.6 3.96 4.78 6.35 7.92 9.53 9.53 11.13 15.09 12.70 19.05 23.83 27.79 31.75 35.71
16 400 406.4 4.19 4.78 6.35 7.92 9.53 9.53 12.70 16.66 12.70 21.44 26.19 30.96 36.53 40.49
18 450 457.2 4.19 4.78 6.35 7.92 11.13 9.53 14.27 19.05 12.70 23.83 29.36 34.93 3,967 45.24
20 500 508 4.78 5.54 6.35 9.53 12.70 9.53 15.09 20.62 12.70 26.19 32.54 38.10 44.45 50.01
22 559 4.78 5.54 6.35 9.53 12.70 9.53 22.23 12.70 28.58 34.93 41.28 47.63 53.98
24 600 610 5.54 6.35 6.35 9.53 14.27 9.53 17.48 24.61 12.70 30.96 38.89 46.02 52.37 59.54
26 660 7.92 12.70 9.53 12.70
28 700 711 7.92 12.70 15.88 9.53 12.70
30 762 6.35 7.92 7.92 12.70 15.88 9.53 12.70
32 800 813 7.92 12.70 15.88 9.53 17.48 12.70
34 884 7.92 12.70 15.88 9.53 17.48 12.70
36 900 914 7.92 12.70 15.88 9.53 19.05 12.70
38 965 9.53 12.70
40 1000 1016 9.53 12.70
42 1067 12.70 15.88 9.53 19.05 12.70
44 1100 1118 9.53 12.70
46 1168 9.53 12.70
48 1200 1219 9.53 12.70

ASME SA106 Grade B Carbon Steel Seamless Pipe NACE Test Requirements

Test Type

Test Standard

Test Method

Acceptance Criteria

HIC Test

NACE TM0284

Immerse specimens in H₂S - containing acidic solution (5% NaCl + 0.5% acetic acid, H₂S - saturated, pH 3.0 - 3.5) for 96h. Check cracks via microscopy, calculate CSR, CLR, CTR.

CSR ≤ 1.5%, CLR ≤ 15%, CTR ≤ 3% (subject to project)

SSCC Test

NACE TM0177

Method A:Four point bending: Apply 80% yield strength stress to specimens in H₂S - containing environment (5% NaCl + 0.5% acetic acid, H₂S - saturated) for 720h to check cracks.
Tension test: Apply constant load (80% yield strength) in H₂S medium to observe cracks.

No visible cracks under specified conditions
