Heat Exchanger Tube, ASTM A269 TP304, 1.4301 Stainless Steel Seamless Tube For Heaters

Brand Name : YUHONG

Model Number : TP304, 1.4301, UNS S30400

Certification : ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015

Place of Origin : China

MOQ : 100 KGS

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : According to Clients' Requirement

Delivery Time : 5 - 90 Work Days

Packaging Details : Ply-Wooden Case /Iron Case/ Bundle with Plastic Cap

Standard : ASTM A269, ASME SA269

Material Grade : TP304, 1.4301, UNS S30400

Type : Seamless,Welded

Outer Diameter : 6 ~ 860mm

Technique : Cold Rolled, Hot Rolled

Surface : Annealing,pickling

Ends : Bevled End, Plain End, Thread End

Application : Construction,Decoration,Industry,boiler,Chemical

Contact Now

Heat Exchanger Tube, ASTM A269 TP304, 1.4301 Stainless Steel Seamless Tube For Heaters

ASTM A269 TP304 stainless steel is the most standard used alloy of this type. Essentially, TP304 is an austenitic chromium alloy which is also known as an "18/8" stainless as the composition of the steel is 18% chromium and 8% nickel. The chromium content enhances the material's considerable resistance to the effects of corrosion and oxidation. The steel needs to be cold worked to generate higher tensile strength. For stainless steel sections which are welded heavily, post-weld annealing may be necessary to provide maximum corrosive resistance. We have manufactured stainless steel tubes for more than 30 years. These stainless steel tubes have various kinds of applications, such as heat exchangers, heaters, air coolers, petrochemical industry, oil and gas plant, etc..

Specifications:

Specification ASTM A269, ASME SA269
Standard ASTM, ASME and API
Size 1 / 8" NB - 24" NB
Types Seamless - Hot Rolled / Cold Drawn
Length Single Random, Double Random & Required Length
Schedule SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Types Seamless / Cold Drawn / Hot Finish / Cold Finish
Form Round Tube, Square Tube, Rectangular Tube, Coiled Tube, “U” Shape, Pan Cake Coils, Hydraulic Tube
Ends Plain End, Beveled End, Treaded

Heat Exchanger Tube, ASTM A269 TP304, 1.4301 Stainless Steel Seamless Tube For Heaters

Equivalent Grade:

Standard SS 304
WERKSTOFF NR. 1.4301
UNS S30400
BS 304S31
JIS SUS 304
EN X5CrNi18-10
GOST 08Х18Н10
AFNOR Z7CN18‐09

Chemical Composition:

C Si Mn Cr Ni S P Fe
0.08 1 2 18 – 20 8 – 11 0.03 0.045 Bal

Mechanical Properties:

Tensile Strength(Mpa) Yield Point(Mpa) Elongation(%) Hardness(HRB) Solution Temperature(º C)
515 205 35 90 1040

Physical Properties:

Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (μm/m/°C) Thermal Conductivity (W/m.K) Specific Heat 0-100°C (J/kg.K) Electrical Resistivity (nΩ.m)
0-100°C 0-315°C 0-538°C 100°C 500°C
8000 193 17.2 17.8 18.4 16.2 21.5 500 720

Applications:

Food Processing Equipments

Chemical Industries

Heat Exchangers

Oil and Gas Equipments

Threaded Fasteners

Paper & Pulp Plants
