ASTM A213 TP316L Stainless Steel Seamless Tube For Heat Exchangers And Boilers

Brand Name : YUHONG

Model Number : TP316L, 1.4404

Certification : ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015

Place of Origin : China

MOQ : 100 KGS

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 1000 Tons Per Month

Delivery Time : 7 - 90 Work Days

Packaging Details : Ply-Wooden Case /Iron Case/ Bundle With Plastic Cap

Standard : ASTM A213, ASME SA213

Material Grade : TP316L / 1.4404 / UNS S31603

Type : Seamless

Outer diameter : 6-630mm

Thickness : 1mm-20mm

Length : 6m or As Your Requirements

Surface : Annealing,Pickling

Application : Construction,Decoration,Industry,boiler,Chemical

Contact Now

ASTM A213 TP316L Stainless Steel Seamless Tube For Heat Exchangers And Boilers

ASTM A213 TP316L Stainless Steel Seamless Tubes is an 18/8 austenitic steel which is improved by means of an adding up of 2.5% Molybdenum in order to offer higher corrosion resistance. These ASTM A213 TP316L Seamless Tubes are used for different applications such as in Process engineering, Medical implants, Condensers, Heat exchangers, Semiconductors, etc.. These Stainless Steel Seamless Tubes are also used in varied industries like in Commercial, Chemical Processing, Oil & Gas, and other high performance related industries.

Speciffications:

Specification ASTM A213, ASME SA213
Size 1 / 8" - 24"
Types Seamless - Hot Rolled / Cold Drawn
Length Single Random, Double Random & Required Length
OD 6 mm up to 914.4 mm OD
Schedule SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Form Round Tubes, Square Tubes, Rectangular Tube, Coiled Tubes, “U” Shape,Etc.
End Plain End, Beveled End, Treaded

Equivalent Material:

MATERIAL UNS NO OLD BRITISH EN/ EURONORM SS JIS
BS NO NAME
TP316L S31603 316S11 1.4404 X2CrNiMo17-12-2 2348 SUS 316L

ASTM A213 TP316L Stainless Steel Seamless Tube For Heat Exchangers And Boilers

Chemical Composition:

C Mn Si P S Cr Mo Ni Fe
0.035 max 2 max 1 max 0.045 max 0.03 max 16 - 18 2 - 3 10 - 14 68.89 min

Mechanical Properties:

Tensile & Hardness Tests Requirements
Tensile Strength
min. MPa [ksi]		 485 [70]
Yield Strength
min. MPa [ksi]		 170 [25]
Elongation in
2", min. %		 35
Brinell Hardness
max. HBW		 192
Vickers Hardness
max. HV		 200
Rockwell Hardness
max. HRB		 90

Applications:

Plumbing

Water Supply Systems

Power Plant

Paper & Pulp Industry

Fabrication Industry

Food Processing Industry

Oil and Gas Tubeline

Chemical Industry

ASTM A213 TP316L Stainless Steel Seamless Tube For Heat Exchangers And Boilers
